               ? Semiconductor Components Industries, LLC, 2011 August, 2011 ? Rev. 10 1 Publication Order Number: RB520S30T1/D RB520S30T1G, RB520S30T5G Schottky Barrier Diode These Schottky barrier diodes are designed for high?speed switching applications, circuit protection, and voltage clamping. Extremely low forward voltage reduces conduction loss. Miniature surface mount package is excellent for hand?held and portable applications where space is limited. Features ? Extremely Fast Switching Speed ? Extremely Low Forward Voltage 0.6 V (max) @ IF = 200 mA ? Low Reverse Current ? ESD Rating: Class 3B per Human Body Model Class C per Machine Model ? These Devices are Pb?Free, Halogen Free/BFR Free and are RoHS Compliant MAXIMUM RATINGS Rating Symbol Value Unit Reverse Voltage VR 30 Vdc Forward Current DC IF 200 mA Stresses exceeding Maximum Ratings may damage the device. Maximum Ratings are stress ratings only. Functional operation above the Recommended Operating Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect device reliability. THERMAL CHARACTERISTICS Characteristic Symbol Max Unit Total Device Dissipation FR?5 Board, (Note 1) TA = 25 °C Derate above 25°C PD 200 1.57 mW mW/°C Thermal Resistance, Junction?to?Ambient RJA 635 °C/W Junction and Storage Temperature Range TJ, Tstg ?55 to +150 °C 1. FR?5 Minimum Pad. ELECTRICAL CHARACTERISTICS (TA = 25 °C unless otherwise noted) Characteristic Symbol Min Typ Max Unit Reverse Leakage (VR = 10 V) IR ? ? 1.0 A Forward Voltage (IF = 200 mA) VF ? ? 0.60 Vdc 30 VOLT SCHOTTKY BARRIER DIODE 1 CATHODE 2 ANODE http://onsemi.com SOD?523 CASE 502 MARKING DIAGRAM 1 2 12 5J = Device Code M = Date Code* = Pb?Free Package *Date Code orientation position may vary depending upon manufacturing location. (Note: Microdot may be in either location) 5J M Device Package Shipping? ORDERING INFORMATION RB520S30T1G SOD?523 (Pb?Free) 4 mm Pitch 3000/Tape & Reel RB520S30T5G SOD?523 (Pb?Free) 2 mm Pitch 8000/Tape & Reel ?For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging Specifications Brochure, BRD8011/D. |
